IEC 60317-70-2:2020
Specifications for particular types of winding wires - Part 70-2: Polyester glass-fibre wound resin/varnish impregnated, bare or enamelled round copper wire, temperature index 155
Ausgabedatum:
2020-06
Edition:
1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 20 VDE-Artnr.: 248890
IEC 60317-70-2:2020 specifies the requirements of polyester glass-fibre wound resin/varnish impregnated bare, grade 1 or grade 2 enamelled round copper winding wires, temperature index 155. The impregnating agent can be, for instance, epoxy, polyester, or polyesterimide resin based. The nominal conductor diameters are specified in Clause 4 of IEC 60317-0-10:2017.
NOTE For this type of wire, the heat shock test is inappropriate and therefore a heat shock temperature cannot be established. Consequently, a class based on the requirements for temperature index and heat shock temperature cannot be specified.
