ISO 80416-2:2001
Basic principles for graphical symbols for use on equipment - Part 2: Form and use of arrows
Ausgabedatum:
2001-07
Edition:
1.0
Sprache: EN - englisch
Seitenzahl: 7 VDE-Artnr.: 223285
ISO 80416-2:2011 lays down the basic principles and the proportions for arrows used to indicate various elements, forces, functions or dimensions. The arrows defined in ISO 80416-2:2011 are used as graphical symbols or graphical symbol elements. When new symbol originals are created or graphical symbols in current use are revised, the principles established in ISO 80416-2:2011 are applicable.
