IEC 60191-6-22:2012
Mechanical standardization of semiconductor devices - Part 6-22: General rules for the preparation of outline drawings of surface mounted semiconductor device packages - Design guide for semiconductor packages Silicon Fine-pitch Ball Grid Array and Silicon Fine-pitch Land Grid Array (S-FBGA and S-FLGA)
Ausgabedatum:
2012-12
Edition:
1.0
Sprache: EN-FR - zweisprachig englisch/französisch
Seitenzahl: 34 VDE-Artnr.: 219486
IEC 60191-6-22:2012 provides the outline drawings and dimensions common to silicon-based package structures and materials of ball grid array packages (BGA) and land grid array packages (LGA).
