E DIN EN IEC 60071-2 VDE 0111-2:2022-06

Insulation co-ordination

Part 2: Application guidelines

(IEC 99/319/CD:2021); Text in German and English
Class/Status: Draft, valid
Released: 2022 -06 Published: 2022-05 -20
VDE Art. No.: 1100707
End of objection deadline: 2022-07-20

This part of IEC 60071 constitutes application guidelines and deals with the selection of insulation levels of equipment or installations for three-phase a.c. systems. Its aim is to give guidance for the determination of the rated withstand voltages for ranges I and II of IEC 60071-1 and to justify the association of these rated values with the standardized highest voltages for equipment. This association is for insulation co-ordination purposes only. The requirements for human safety are not covered by this document. This document covers three-phase a.c. systems with nominal voltages above 1 kV. The values derived or proposed herein are generally applicable only to such systems. However, the concepts presented are also valid for two-phase or single-phase systems.
