Cover IEC 62228-5:2021
größer

IEC 62228-5:2021

Integrated circuits - EMC evaluation of transceivers - Part 5: Ethernet transceivers

Circulation Date: 2021-04
Edition: 1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 223 VDE Artno.: 249888

Content

IEC 62228-5:2021 specifies test and measurement methods for EMC evaluation of Ethernet transceiver ICs under network condition. It defines test configurations, test conditions, test signals, failure criteria, test procedures, test setups and test boards. It is applicable for transceiver of the Ethernet systems
100BASE-T1 according to ISO/IEC/IEEE 8802-3/AMD1;
100BASE-TX according to ISO/IEC/IEEE 8802-3;
1000BASE-T1 according to ISO/IEC/IEEE 8802-3/AMD4
and covers
the emission of RF disturbances;
the immunity against RF disturbances;
the immunity against impulses;
the immunity against electrostatic discharges (ESD).
