IEC 61557-5:2019
Electrical safety in low voltage distribution systems up to 1 000 V AC and 1 500 V DC - Equipment for testing, measuring or monitoring of protective measures - Part 5: Resistance to earth
Circulation Date:
2019-07
Edition:
3.0
Language: EN-FR - bilingual english/french
Seitenzahl: 24 VDE Artno.: 247860
IEC 61557-5:2019 specifies the requirements applicable to measuring equipment for measuring the resistance to earth using an AC voltage. IEC 61557-5:2019 cancels and replaces the second edition published in 2007. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition:
a) definitions and symbols in Clause 3 modified;
b) subclauses in Clause 4 restructured and aligned with other parts of the series;
c) limits for reduced voltages 25 V RMS or 35 V peak removed from 4.5;
d) requirements for clamps added;
e) marking for rated voltages to earth and measurement category added to Clause 5;
f) warning about absence of hazardous voltage added in Clause 5;
g) the term 'percentage operating uncertainty' replaced by 'operating uncertainty' in Clause 6;
h) equation for uncertainty corrected in Table 1;
i) new Annex A on test measurements with loop clamps added.
