IEC 61169-4:2008
Radio-frequency connectors - Part 4: RF coaxial connectors with inner diameter of outer conductor 16 mm (0,63 in) with screw lock - Characteristic impedance 50 O (type 7-16)
Circulation Date:
2008-04
Edition:
1.0
Language: EN-FR - bilingual english/french
Seitenzahl: 45 VDE Artno.: 220493
IEC 61169-4:2008 provides information and rules for the preparation of detail specifications (DS) for type 7-16 R.F. coaxial connectors with screw lock. It describes the interface dimensions for general purpose grade 2 connectors, dimensional details for standard test connectors, grade 0, together with gauging information and the mandatory tests selected from QC 22000 (IEC 61169-1), applicable to all DS relating to type 7-16 connectors.
